Leveraging 182mm N-type monocrystalline technology, 144-cell SMBB half-cell design, and bifacial dual-glass construction, this module delivers 585W to 605W power with a peak efficiency of 23.4%, optimized for distributed generation scenarios. With a lightweight, compact form factor engineered for rooftop compatibility, this 144-cell distributed generation solar panel maximizes limited rooftop space utilization, enhances energy yield in complex urban environments, and delivers reliable long-term performance for distributed solar projects.
Adopts SMBB half-cut cell technology, delivering a power output of 585–605W with a maximum efficiency of 23.4%. This significantly boosts power generation per unit area.
Built on N-type technology, it features extremely low Light-Induced Degradation (LID), minimizing early-stage power loss. Backed by 15-year product warranty and 30-year linear power output warranty, it retains at least 87.4% of its initial power after 30 years, outperforming conventional modules in long-term performance.
Optimized for low-light environments (e.g., cloudy days, mornings/evenings). The bifacial design provides an additional rear-side power gain of up to 80±5%, significantly increasing overall energy yield, especially in high-reflectivity installation scenarios (e.g., white roofs, sandy ground).
Certified to withstand harsh conditions: passed third-party salt spray and ammonia corrosion tests, IP68-rated junction box, and high static load resistance (5400Pa front / 2400Pa rear), ensuring stable operation in coastal, humid, and high-wind areas.
Meets major international standards (IEC, CE, ISO, CQC), with Class II protection and IEC Class A fire rating, suitable for diverse global applications including utility-scale farms, commercial & industrial rooftops, and residential systems.
| Parameter | Details |
| Power Range (STC) | 585-605W |
| Max Efficiency | 23.4% |
| Dimensions | 2279×1134×30mm |
| Weight | 31.5kg |
| Maximum System Voltage | 1500V |
| Front Static Load | 5400Pa |
| Rear Static Load | 2400Pa |
| Operating Temperature | -40℃~ +85℃ |
| Bifaciality | 80%+5% |
| Connector | MC4 compatible |
| Warranty | 15-year product/30-year linear power output |
Ideal for commercial & industrial distributed systems, utility-scale ground-mounted power plants, and large residential rooftops, the LC182N-144MS series offers a high-power, cost-effective solution to maximize solar energy production and return on investment across various scenarios.
What kind of warranty and certifications does this module have?
We offer comprehensive protection and compliance:
• Warranty: 15-year product warranty and 30-year linear power output warranty. After 30 years, the module retains at least 87.4% of its initial power.
• Certifications: Compliant with IEC 61215:2021, IEC 61730:2023, ISO 9001/14001/45001, CE, and CQC standards, suitable for global installations.
What are the electrical and mechanical specifications of the LC182N-144MS?
Key specs include:
• Electrical (STC): Power range 585–605W, max system voltage 1500V, temperature coefficient of Pmax: -0.28%/°C.
• Mechanical: Dimensions 2279×1134×30mm, weight 31.5kg, MC4-compatible connectors, 2.0+2.0mm AR-coated glass.
• Operating Range: -40°C ~ +85°C, with Class II protection and IEC Class A fire rating.
